Part Number : 2119AB-11

The Mitutoyo 2119AB-11 is a high-precision dial gauge designed for accurate linear measurements. It offers a 5 mm measuring range with a 0.001 mm graduation, making it suitable for fine inspection tasks. The flat back design allows for stable mounting on flat surfaces or magnetic bases, ensuring reliable measurements. Built to ANSI/AGD Type 2 standards, it ensures compatibility with standard fixtures and holders. The gauge features a clear, easy-to-read dial, enhancing visibility and reducing reading errors. Its durable construction includes a scratch-resistant, anti-glare crystal for long-lasting clarity.

Availability: Sold out

Free UAE shipping available

Specifications
Features
Downloads

Contact point	Carbide tipped
Dial Reading	0-10-0
Graduation	0.001 mm
Hysteresis	2.5 µm
Inch-Metric	Analog
Measuring Force	0.4 - 1.5 N
Range	5 mm
Repeatability	+/-0.3 µm
Stem Dia	9.52 mm Or 0.375 Inch
Thread type	4-48UNF
Type	ANSI/AGD Standard
Type	Dial Gauge

5 mm Measuring Range – Suitable for high-precision inspection over a moderate range.
0.001 mm Graduation – Delivers ultra-fine resolution for detailed and accurate readings.
Flat Back Design – Allows stable and secure mounting on flat surfaces or magnetic bases.
Jeweled Bearings – Provides smooth, low-friction movement and long-lasting durability.
ANSI/AGD Type 2 Compliant – Meets standardized specifications for universal compatibility.
Scratch-Resistant, Anti-Glare Crystal – Ensures clear visibility and protects against wear in industrial use.
