Omron EE-SX675, Through Beam Photoelectric Sensor, Fork Sensor, 5 mm Detection Range

Part Number : EE-SX675

Availability: Sold out

Detailed Description
Specifications

Omron EE-SX67 Series Photoelectric Sensor, 5mm Detection Range, Infrared Light Source - EE-SX675

This photoelectric sensor is an advanced industrial sensing device designed for precise object detection. Utilising a fork sensor style, this infrared photoelectric sensor operates on the through beam principle, ensuring reliable performance in a variety of environments. The sensor features a compact design suitable for tight spaces.

Features & Benefits

• NPN output provides flexibility in control requirement
• Maximum detection range of 5mm improves sensing accuracy
• High-speed response time of 0.17ms ensures rapid detection
• Robust PBT housing material enhances durability in harsh conditions

Applications

• Used for object detection in automated assembly lines
• Suitable for packaging machinery requiring precise part alignment
• Can be integrated into conveyor systems for material handling
• Utilised in robotics for reliable position sensing
• Ideal for detecting objects in printing and labelling systems

What is the significance of the IP50 rating for this device?

The IP50 rating indicates the sensor is protected against solid objects larger than 1mm, providing reliability in environments with minimal dust exposure.

How does the light/dark switching feature benefit installation flexibility?

This functionality allows users to configure the sensor for their specific application needs, enabling it to detect either the presence or absence of objects based on application requirements.

What type of connection is provided with this model?

It offers a 4-pin connector for electrical connections, simplifying installation and ensuring secure connectivity in various applications.

What environments are suitable for the operational temperature range of this sensor?

With an operating range from -25°C to +55°C, it is suitable for both moderately cold and warm environments, making it versatile for various industrial settings.

How does the response time of 0.17ms impact its performance?

The high-speed response time allows for accurate and rapid detection of moving objects, essential for maintaining efficiency in fast-paced automation processes.

Brand	Omron
Sensor Style	Fork
Detection Type	Through Beam
Detection Range	5 mm
Output Type	NPN
Switching Mode	Light / Dark switching
Electrical Connection	4 Pin Connector
Maximum DC Voltage	24V
Terminal Type	Connector
Light Source	Infrared
IP Rating	IP50
Maximum Current	12 mA
Response Time	0.17 ms
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+55°C
Housing Material	PBT
Series	EE-SX67
Standards Met	CE
