OMRON VX-53-1C23 | Long Hinge Lever Micro Switch | 5 A @ 250 V AC, SPDT, Tab Terminal
OMRON VX-53-1C23 is a long hinge lever micro switch with tab terminals, offering an SPDT contact with a 5 A at 250 V AC rating. Its IP40-rated body is listed with an operating force of 0.2 N and silver alloy contacts.
- Actuator: Long Hinge Lever
- Terminals: Tab
- Contact: SPDT, rated 5 A at 250 V AC
- Protection: IP40
- Operating temperature: -25 to +80 °C
- Mechanical life: 50,000,000 operations
- Detailed Description
- Specifications
- Downloads
Omron Miniature - Low Operating Force
V3 style housing
RoHS compliant
Contact rating: 5A @ 250Vac resistive
Contact configuration: SPDT
Solder/Quick - Connect terminals (#187)
Approvals
| Brand | Omron |
| Actuator Type | Long Hinge Lever |
| Terminal Type | Tab |
| Contact Configuration | SPDT |
| IP Rating | IP40 |
| Contact Current Rating | 5 A @ 250 V ac |
| Minimum Operating Temperature | -25 °C (-13 °F) |
| Maximum Operating Temperature | +80 °C (176 °F) |
| Contact Material | Silver Alloy |
| Mechanical Life | 50000000Operations |
| Operating Temperature Range | -25 → +80 °C (-13 to 176 °F) |
| Operating Force | 0.2 N |
