OMRON VB-3221 | Roller Plunger Limit Switch | SPDT, IP67, Die-Cast Aluminium, 10 A

Part Number : VB-3221

With NO/NC contacts, the OMRON VB-3221 is a roller plunger limit switch rated 10 A at 250 V AC. For the VB-3221, OMRON lists an IP67 rating, a die-cast aluminium housing and an operating range of -10 to +80 °C.

  • NO/NC contact configuration; SPDT pole and throw
  • Maximum current: 10 A at 250 V AC and 600 mA at 125 V DC; maximum voltage: 250 V AC / 250 V DC
  • IP67 enclosure rating; die-cast aluminium housing
  • Dimensions: 114 mm × 68 mm × 70 mm (L × W × D)
  • Operating temperature: -10 to +80 °C
  • Mechanical life: 5,000,000 operations
Availability: in stock
For pricing, please contact our experts.
