Omron V-166-1A5, Roller Lever Micro Switch, Solder Terminal, 16 A @ 250 V ac, SP-CO, IP40

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron V-166-1A5, Roller Lever Micro Switch, Solder Terminal, 16 A @ 250 V ac, SP-CO, IP40

Name: Omron V-166-1A5, Roller Lever Micro Switch, Solder Terminal, 16 A @ 250 V ac, SP-CO, IP40
Brand: OMRON
SKU: V-166-1A5
Availability: OutOfStock

Part Number : V-166-1A5

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron Miniature Basic Switch (16A)

16 A contact rating

Brand	Omron
Actuator Type	Roller Lever
Terminal Type	Solder
Contact Current Rating	16 A @ 250 V ac
Contact Configuration	SP-CO
IP Rating	IP40
Operating Force	1.23 N
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+80°C
Contact Material	Silver Alloy
Case Material	Thermoplastic
Mechanical Life	50000000Operations
Release Force	0.14N
Operating Temperature Range	-25 → +80°C
