OMRON SSG-01H | Pin Plunger Subminiature Micro Switch | 100 mA @ 30 V dc, SPDT, Solder Terminal
The 100 mA at 30 V dc rating of the OMRON SSG-01H suits SPDT switching from a pin plunger actuator, with connection via solder terminals. The pin plunger model uses gold alloy contacts. Actuation needs 1.5 N, with release at 0.25 N.
- Contact configuration: SPDT (single-pole double-throw)
- Works from -25 to +125 °C
- Rated for 10 million operations (mechanical)
- IP40 enclosure rating
- Contact rating: 100 mA at 30 V dc
- Detailed Description
- Specifications
- Downloads
Subminiature Microswitch
Conforms to EN61058-1
PCB terminal models are resistant to flux
A wide operating temperature range of -25°C to 125°C
Contact configuration: SPDT
Dimensions (body): H9.9mm, W19.8mm, D6.4mm
Approvals
| Brand | Omron |
| Actuator Type | Pin Plunger |
| Terminal Type | Solder |
| Contact Configuration | SPDT |
| IP Rating | IP40 |
| Contact Current Rating | 100 mA @ 30 V dc |
| Minimum Operating Temperature | -25 °C (-13 °F) |
| Maximum Operating Temperature | +125 °C (257 °F) |
| Contact Material | Gold Alloy |
| Mechanical Life | 10000000Operations |
| Operating Temperature Range | -25 → +125 °C (-13 to 257 °F) |
| Operating Force | 1.5 N |
| Release Force | 0.25N |
