Omron NX-EIC202, NX Series Safety Module, 20.4 → 28.8 V dc

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron NX-EIC202, NX Series Safety Module, 20.4 → 28.8 V dc

Name: Omron NX-EIC202, NX Series Safety Module, 20.4 → 28.8 V dc
Brand: OMRON
SKU: NX-EIC202
Availability: OutOfStock

Part Number : NX-EIC202

NX-series EtherNet/IP Coupler, 2 ports, supports local safety, 63 I/O units, max I/O current 10 A, screwless push-in connector, delivered with end cover

Availability: Sold out

Detailed Description
Specifications
Features

Omron NX-EIC EtherNet/IP Coupler Unit

The EtherNet/IP Coupler Unit is the link between the EtherNet/IP multi-vendor network and the NX-series I/O Units and Safety Units. With wide variety of the I/O Units and Safety Units, the NX-series is the perfect match for the CJ-series and multi-vendor controllers.

Up to 63 NX-IO Units can be connected to one EtherNet/IP Coupler Unit
Standard and high-performance units can be mixed
Each Coupler plus its I/O form just a single EtherCAT node on the network
I/O control and safety control can be integrated by connecting Units for safety
The IP address can be found on the label on the Unit, without using software
Slave configuration by Sysmac Studio can be done centrally via the controller, or on-the-spot using the Coupler's built-in USB port
Input per Coupler Unit: Maximum 504 bytes, Output per Coupler Unit: Maximum 504 bytes

Brand	Omron
Series	NX
Type	Communication Module
Supply Voltage	20.4 → 28.8 V dc
Mounting Style	DIN Rail
Dimensions	106 x 48.1 x 80 mm

NX-series EtherNet/IP Coupler, 2 ports, supports local safety, 63 I/O units, max I/O current 10 A, screwless push-in connector, delivered with end cover
