Omron H3CR-HRL AC200-240 M, H3CR Series DIN Rail Mount Timer Relay, 200 → 240V ac, 2-Contact, 0.05 → 12s, DPDT

Name: Omron H3CR-HRL AC200-240 M, H3CR Series DIN Rail Mount Timer Relay, 200 → 240V ac, 2-Contact, 0.05 → 12s, DPDT
Brand: OMRON
SKU: H3CR-HRL AC200-240 M
Availability: OutOfStock

Part Number : H3CR-HRL AC200-240 M

Availability: Sold out

Detailed Description
Specifications

Omron Timer Relay

The Omron H3CR series multifunction relay has an OFF delay timer along with 2 changeover contacts and is DIN rail mount. The relay requires a supply voltage ranging between 200VAC and 240VAC and a maximum current rating of 5A. It has an adjustable time range between 0.05sec and 12min.

Features and Benefits

• Contact configuration is DPDT
• Crimp terminal type
• Long power OFF delay time
• Models with forced reset input are available
• Operating temperature ranges between -10°C and 55°C

Applications

• Industrial application
• Timing control

Certifications

• CSA approved
• IEC60664
• UL approved

Brand	Omron
Supply Voltage	200 → 240V ac
Mounting Type	DIN Rail
Mode of Operation	OFF Delay
Time Range	0.05 → 12s
Number of Contacts	2
Number of Timer Functions	Multi Function
Contact Configuration	DPDT
Time Increment	Minutes, Seconds
Maximum Current	5A
Maximum Voltage	240V ac
Switch Configuration	DPDT
Terminal Type	Crimp
Minimum Voltage	200V ac
Power Supply	External
Width	48mm
Depth	93mm
Maximum Operating Temperature	+55°C
Series	H3CR
Length	48mm
