OMRON E3NX-CA51 2M | IO-Link Fibre Amplifier | PNP, White LED, IP20
This OMRON E3NX-CA51 2M fibre amplifier pairs a PNP output with an IO-Link interface. It uses a white LED and is housed in IP20 polycarbonate for DIN rail mounting.
- PNP output
- IO-Link interface
- Response 250 µs high speed, 1 ms standard
- 1.08 W at 10 to 30 V DC
- 104.8 x 33.5 x 10 mm
- CE, IEC 60947-1, UL certified
- Detailed Description
- Specifications
- Downloads
E3NX-CA Series Colour Mark Fibre Amplifiers
Features and Benefits
• The amplifier is able to handle glossy workpieces and colourful packaging offering stable detection on items previously troublesome for conventional systems.
• Reduces the number of troubleshooting requests.
• Users can automatically adjust the optimum incident level and intensity using a button.
• Advanced smart tuning, consistent for all users.
• The amplifier detects all RGB wavelengths included in light reflected from the workpiece, and RGB data can be displayed on the unit.
• IoT compatible.
• S/N ratio improved four times.
• Maintenance signal output to reduce downtime.
| Brand | Omron |
| IP Rating | IP20 |
| Terminal Type | Pre-Wired |
| Response Time | 1 (Standard Mode) ms, 16 (Giga-Power Mode) ms, 250 (High Speed Mode) μs, 50 (Super High Speed Mode) μs |
| Supply Voltage | 10 → 30 V dc |
| Output Type | PNP |
| Light Source | White LED |
| Housing Material | PC |
| Length | 104.8 mm (4.13 in) |
| Maximum Operating Temperature | +40 (30 Units)°C |
| Minimum Operating Temperature | -25 (30 Units)°C |
| Dimensions | 104.8 x 33.5 x 10 mm (4.13×1.32×0.394 in) |
| Electrical Connection | Pre-Wired Cable |
| Power Consumption | 1.08 W |
| Width | 33.5 mm (1.32 in) |
| Depth | 10 mm (0.394 in) |
| Interface | IO-Link |
| Mounting Type | DIN Rail |
| Standards Met | CE, IEC 60947-1, UL Certified |
