Omron E2A-S08KN04-WP-B1 2M, Inductive Threaded Barrel Proximity Sensor, M8, 4 mm Detection, PNP NO, 12 → 24 V dc

Name: Omron E2A-S08KN04-WP-B1 2M, Inductive Threaded Barrel Proximity Sensor, M8, 4 mm Detection, PNP NO, 12 → 24 V dc
Brand: OMRON
SKU: E2A-S08KN04-WP-B1 2M
Availability: OutOfStock

Part Number : E2A-S08KN04-WP-B1 2M

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron E2A Series Proximity Sensor, 4mm Detection Range, IP67 - E2AS08KN04WPB12M

This proximity sensor is designed for effective sensing in industrial environments. With a cylindrical shape and a threaded barrel, it achieves reliable detection at a distance of 4mm. Its robust stainless steel casing ensures longevity even in demanding settings. The sensor meets the IP67 protection standard, making it suitable for tough conditions.

Features & Benefits

• Detects objects up to 4mm away
• PNP output for straightforward integration with control systems
• High-speed switching frequency of 1kHz
• Durable stainless steel body for extended use
• IP67 rating for moisture and dust resistance
• Pre-cabled connection for simplified installation

Applications

• Used in automated assembly lines
• Suitable for packaging machinery
• Effective in robotics for precise positioning
• Employed in conveyor systems for object detection
• Ideal for detecting product presence in manufacturing

Can it operate in extreme temperatures?

Yes, it functions between -40°C to +70°C.

Will it work in a dusty environment?

Yes, it has an IP67 rating for resistance to dust and moisture.

Is it capable of high-speed operation?

Yes, it supports a maximum frequency of 1kHz.

Can it be easily integrated into existing systems?

Yes, it features a PNP output for straightforward integration.

Does it require special mounting techniques?

It can be mounted non-flush for flexible installation.

Brand	Omron
Thread Size	M8
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	4 mm
Output Function	NO
Digital Switching Output Type	PNP
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	12 → 24 V dc
Length	40mm
IP Rating	IP67
Mounting Type	Non-Flush
Housing Material	Stainless Steel
Maximum DC Voltage	32V
Minimum Operating Temperature	-40°C
Maximum Switching Frequency	1kHz
Short Circuit Overload Protection	Yes
Depth	5.8mm
Reverse Polarity Protection	Yes

Omron E2A-S08KN04-WP-B1 2M, Inductive Threaded Barrel Proximity Sensor, M8, 4 mm Detection, PNP NO, 12 → 24 V dc

DOWNLOAD CATALOG

E2A-S08KN04-WP-B1 2M Datasheet 0900766b8161927c
