OMRON D4N-4A2G | D4N Roller Lever Limit Switch | NO/NC, DPST, M20, 45 mm Depth
Part Number : D4N-4A2G
Listed as a D4N series roller lever limit switch, the OMRON D4N-4A2G has NO/NC contacts. It has an M20 connection.
- NO/NC contact configuration
- DPST pole and throw
- M20 connection
- Dimensions: 64 mm × 31 mm × 45 mm (L × W × D)
- Mechanical life: 15,000,000 cycles
For pricing, please contact our experts.
- Detailed Description
- Specifications
- Downloads
D4N Series, Miniature Safety Limit Switch
The D4N series from Omron is a miniature safety limit switch with a plastic housing, two built-in contacts and a wide range of head and actuator types.
Direct opening mechanism
Various actuators
Double insulation
Standardized gold clad contacts provide high contact reliability
Can be used with both standard loads and micro loads
Free of lead, cadmium, and hexavalent chrome, reducing the burden on the environment
Conforms to EN115 and EN81-1
Various actuators
Double insulation
Standardized gold clad contacts provide high contact reliability
Can be used with both standard loads and micro loads
Free of lead, cadmium, and hexavalent chrome, reducing the burden on the environment
Conforms to EN115 and EN81-1
Safety Limit Switch
| Brand | Omron |
| Series | D4N |
| Actuator Type | Roller Lever |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | NO/NC |
| Length | 64 mm (2.52 in) |
| Width | 31 mm (1.22 in) |
| Depth | 45 mm (1.77 in) |
| Mechanical Life | 15000000Cycles |
| Connection Type | M20 |
OMRON D4N-4A2G | D4N Roller Lever Limit Switch | NO/NC, DPST, M20, 45 mm Depth
