OMRON D4N-2120 | Roller Lever Limit Switch | 1NC/1NO Snap Action, G1/2, Metal Housing
With 1NC/1NO contacts, the OMRON D4N-2120 is a roller lever limit switch rated 10 A max at 240 V AC. The switch has an IP67 rating and a metal housing.
- Resin lever with resin roller
- G1/2 single-conduit entry
- 1NC/1NO contact configuration; DPST pole and throw, snap-action operation
- Maximum current: 10 A; maximum voltage: 240 V AC
- IP67 enclosure rating
- Metal housing
- Detailed Description
- Specifications
- Features
- Downloads
Roller lever (resin lever, resin roller) Actuator
IP67 Degree of protection
Can be used with both standard loads and microloads
| Brand | Omron |
| Actuator Type | Roller |
| IP Rating | IP67 |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | 1NC/1NO |
| Maximum Current | 10A |
| Maximum AC Voltage | 240V |
| Housing Material | Metal |
Limit switch, Roller lever (resin lever, resin roller), 1NC/1NO (snap-action), 1NC/1NO (snap-action), G1/2 (1-conduit)
