OMRON D4MC-2020 | Short Hinge Roller Lever Limit Switch | SPDT, 480 V AC, IP67
The OMRON D4MC-2020 is an enclosed D4MC series switch with a short hinge roller lever and 2.94 N operating force. Its SPDT snap-action NO/NC contacts are rated to 480 V AC and 250 V DC.
- Short hinge roller lever, 2.94 N
- SPDT, NO/NC
- 480 V AC / 250 V DC max
- IP67, screw connection, CE
- -10 to +80 °C, 10,000,000 operations
- 70 x 48.5 x 21.7 mm, side mounting
- Detailed Description
- Specifications
- Features
- Downloads
Omron Limit Switch, 2.94 N Opearting Force, IP67 - D4MC-2020
Features & Benefits
• Snap action design provides rapid response time
• Operating force of 2.94N for reliable actuation
Applications
• Applied in automation systems requiring position feedback
• Suitable for use in packaging and assembly lines
• Ideal for lifts and escalators for limit sensing
Can it operate in high-temperature environments?
Will it perform well in wet or dusty conditions?
Is it durable enough for frequent operation?
| Brand | Omron |
| Series | D4MC |
| Actuator Type | Short Hinge Roller Lever |
| IP Rating | IP67 |
| Pole and Throw Configuration | SPDT |
| Normal State Configuration | NO/NC |
| Maximum Current | ac 3 A, dc 250mA |
| Maximum AC Voltage | 480V |
| Action Type | Snap Action |
| Length | 70 mm (2.76 in) |
| Maximum Operating Temperature | +80 °C (176 °F) |
| Width | 48.5 mm (1.91 in) |
| Depth | 21.7 mm (0.854 in) |
| Minimum Operating Temperature | -10 °C (14 °F) |
| Mechanical Life | 10000000Operations |
| Maximum DC Voltage | 250V |
| Connection Type | Screw |
| Standards Met | CE |
| Mounting Orientation | Side |
| Operating Force | 2.94 N |
Enclosed switch, short hinge roller lever, SPDT, 10 A
