Omron 61F-LS-CP08-SRB, 61F-LS-CP08 Series Level Controller -, 24 V ac 3 Relay

Name: Omron 61F-LS-CP08-SRB, 61F-LS-CP08 Series Level Controller -, 24 V ac 3 Relay
Brand: OMRON
SKU: 61F-LS-CP08-SRB
Availability: OutOfStock

Part Number : 61F-LS-CP08-SRB

Floatless level switch, plug-in, high functionality type, adjustable sensitivity, sequential operation, 8 pins, relay output, 24 VAC. The Following are the applications , Acid chemicals, Alkali chemicals, Distilled water, Liquids with high specific resistance, Liquids with low specific resistance, Salt water

Availability: Sold out

Detailed Description
Specifications
Features

Omron 61F-LS-CP08 Series Level Controller, 3 Inputs, 5A Current - 61F-LS-CP08-SRB

This level controller is designed for efficient liquid level management within various industrial applications. Equipped with three inputs and a relay output type, the device operates at a supply voltage of 24V AC. It maintains a compact plug-in design at 84 mm in length and is built to function effectively in temperatures ranging from -10°C to +55°C. The CE certified device offers reliable performance for effective level control systems.

Features & Benefits

• Compact design ensures easy installation and saves space
• High response speed allows for quick level adjustments
• Supports long wiring distances of up to 4 km
• Compatible with the 61F-GP-N series for straightforward maintenance
• Adjustable sensitivity enhances versatility for multiple liquids
• Plug-in termination simplifies connections and replacements

Applications

• Used for automatic water supply control in tanks
• Applied in drainage operations where liquid levels need monitoring
• Suitable for controlling levels in high-temperature environments
• Utilised in systems requiring long-distance wiring solutions
• Works effectively with various types of liquids, including purified and sewage water

What is the response time of this controller when adjusting liquid levels?

The response time ranges from 1.5 to 3 seconds, ensuring quick adjustments for effective level control.

Can the sensitivity be modified for different types of liquids?

Yes, the sensitivity can be adjusted, with an operating resistance range from 0 to 100 kΩ, allowing tailored settings for various liquid properties.

What temperature range can this device operate in effectively?

The device operates efficiently in ambient temperatures from -10°C to +55°C, making it versatile for different industrial environments.

How does this controller facilitate maintenance and replacement?

Its compatibility with the 61F-GP-N series means easy replacement during maintenance, reducing downtime and service disruptions.

What are the implications of using this controller in sensitive environments?

The level controller's design prevents interference, allowing reliable operation even in environments with long wiring distances while maintaining functionality in high-temperature settings.

Brand	Omron
Number of Inputs	3
Supply Voltage	24 V ac
Overall Length	84 mm
Response Time	1.5 → 3 s
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+55°C
Series	61F-LS-CP08
Termination Type	Plug-In
Standards Met	CE
Current Rating	5 A
Output Type	Relay

Sequential operation
