Mitutoyo 314-352-30 | 3-Flute V-Anvil Digital Micrometer | 0.4-1 in, with groove
Covering 0.4-1 in, the 314-352-30 V-anvil micrometer from Mitutoyo measures the outside diameter of 3-flute taps, reamers and end mills. On this 0.4-1 in size, the V-anvil has a centreline groove for measuring tap pitch diameter by the single-wire method.
- Covers 0.4-1 in three-flute tool diameters
- Grooved anvil for single-wire pitch diameter checks
- Reads in 0.00005 in steps; main unit 410 g
- 60° V-anvil prism; locking 6.35 mm spindle with 0.75 mm pitch
- ZERO/ABS key plus data output; approx. 2.4 years per battery
- Comes with setting standard, key, battery and box
- Specifications
- Features
- Downloads
| Part Number | 314-352-30 |
| Brand | Mitutoyo |
| Range | 0.4-1 in |
| Flutes | 3 |
| Prism Angle | 60° |
| Digital Step | 0.00005 in |
| Flatness | 0.000012 in |
| Units | Inch/Metric |
| Spindle | 6.35 mm, with lock, 0.75 mm pitch |
| Data Output | Yes |
| Battery Life | Approx. 2.4 years |
| Mass | 410 g |
| Supplied With | Box, setting standard, key, 1 battery |
| Anvil | With centreline groove |
This Digimatic V-Anvil Micrometer helps you measure cutting tools and taps.
It offers the following benefits:
- It measures the outside diameter of cutting tools (such as taps, reamers, end mills) which have three or five flutes.
- V-anvils with a centreline groove are available for measuring the pitch diameter of taps by the single-wire method.
