Mitutoyo 2905S-10 | Reverse Reading Dial Indicator | 0.05 in Range, 0.0001 in Graduation
Mitutoyo's 2905S-10 reverse reading dial indicator covers 0.05 in with a 0.0001 in graduation. The 2905S-10 is intended for general measurement applications.
- 10-0 dial graduated in the reverse direction; movement runs in jewelled bearings
- Rated accuracy ±0.0001 in; 2 N or less measuring force
- Shockproof construction; graduation 0.0001 in
- Analogue dial, no data output; measuring range of 0.05 in
- Specifications
- Features
- Downloads
| Part Number | 2905S-10 |
| Brand | Mitutoyo |
| Range | 0.05 in |
| Graduation | 0.0001 in |
| Accuracy | ±0.0001 in |
| Dial Reading | 10-0 |
| Dial Type | Reverse reading |
| Measuring Force | 2 N or less |
| Bearing | Jewelled |
- The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.
- Secured adhesion between the outer frame and crystal as well as the use of an O-ring ensure countermeasures against water and oil permeation via the front face.
- The stem spindle is made of high-strength quench-hardened stainless steel which resists strenuous use.
- A carbide contact point is used.
- The grand gear uses stainless steel that is resistant to wear and deformation.
- Application of a hard coating on the surface of the crystal makes the gauge highly scratch- and chemical-resistant
