Mitutoyo 2514A | Lug Back Dial Indicator | 0.5 in, 0.0005 in, Accuracy ±0.0005 in
Reading in 0.0005 in steps across 0.5 in of travel, the Mitutoyo 2514A is a lug back dial indicator with a stated accuracy of ±0.0005 in. Part of Series 2, it is used for linear measurement and inspection, and its lug back provides secure mounting.
- Dial reading ±0-50; measuring force 0.4 - 1.8 N
- Stated accuracy: ±0.0005 in
- 2514A repeatability: ±0.0001 in; hysteresis: 0.00016 in
- 4-48 UNF thread and 9.52 mm or 0.375 in stem on the 2514A
- 2514A weight 164 g, carbide-tipped contact
- Analogue inch dial on the 2514A
- Specifications
- Features
- Downloads
| Part Number | 2514A |
| Brand | Mitutoyo |
| Series | 2 |
| Product Type | Lug Back Dial Indicator |
| Range | 0.5 in |
| Graduation | 0.0005 in |
| Dial Reading | ±0-50 |
| Measuring Force | 0.4 - 1.8 N |
| Hysteresis | 0.00016 in |
| Repeatability | ±0.0001 in |
| Stem Diameter | 9.52 mm or 0.375 in |
| Back | Lug back |
| Thread | 4-48 UNF |
| Accuracy | ±0.0005 in |
- Lug Back Design: Allows for easy mounting and stable positioning.
- Graduation of 0.0005 inch: Provides fine precision for highly accurate measurements.
- Accuracy of ±0.0005 inch: Ensures reliable and consistent performance in precise applications.
- Range of 0.5 inch: Suitable for measuring moderate deviations within a 0.5-inch range.
- Durable Construction: Built to withstand industrial use and maintain long-term performance.
- Clear Dial Face: Ensures easy reading and quick interpretation of measurements.
