Mitutoyo 201-104 Dial Snap Gauge without Indicator 75-100mm
Part No. 201-104 | Range 75–100 mm | Without Indicator
Product Overview
The Mitutoyo 201-104 is a dial snap gauge frame designed for fast, repeatable GO/NG checking of shaft and cylinder diameters from 75–100 mm. It is supplied without an indicator, allowing you to fit a compatible dial or digital indicator according to your measurement requirements.
A dial snap gauge is designed for repeated in-process inspection. The gauge can be set to the required nominal dimension, after which each workpiece can be positioned between the anvils and checked quickly using the indicator reading. This makes the 201-104 suitable for production and machining environments where repeated dimensional checks are required.
The gauge features wide, flat carbide anvils that provide stable, hard-wearing contact with the workpiece. A 2 mm anvil retracting stroke helps with inserting and removing parts, while the adjustment nut allows the measuring range to be adjusted to the required dimension.
Because the 201-104 is supplied without an indicator, users can select a compatible dial or digital indicator based on their preferred resolution and application requirements.
For the next size range, the Mitutoyo 201-105 covers 100–125 mm.
Key Benefits
-
Fast GO/NG checking of shaft and cylinder diameters from 75–100 mm
-
Wide, flat carbide anvils for stable and wear-resistant contact
-
2 mm anvil retracting stroke for convenient loading and unloading
-
Adjustment nut for setting the measuring range
-
Supplied without an indicator for flexible indicator selection
-
Suitable for repeated production and in-process dimensional inspection
-
Genuine Mitutoyo part supplied by General Tech Services LLC in Saudi Arabia
Who This Product Is Best For
-
Production lines performing repeated GO/NG checks on turned and ground shafts
-
Quality inspectors checking batches of cylindrical components
-
Machine shops that already have compatible dial or digital indicators
-
Workshops regularly inspecting diameters within the 75–100 mm range
-
Users who require a Mitutoyo snap gauge frame without a supplied indicator
How to Use It
-
Fit a suitable compatible dial or digital indicator to the gauge frame.
-
Use the adjustment nut to set the anvils to the required nominal dimension using a suitable master or reference standard.
-
Zero the indicator against the reference and establish the required tolerance limits.
-
Position each workpiece between the anvils.
-
Read the indicator and determine the GO or NG condition according to the established limits.
Frequently Asked Questions
What is the Mitutoyo 201-104 used for?
The Mitutoyo 201-104 is used for quick, repeatable GO/NG checks of shaft and cylinder diameters from 75–100 mm, particularly during production and in-process inspection.
Does the 201-104 come with an indicator?
No. The 201-104 is supplied without an indicator, allowing you to fit a compatible dial or digital indicator according to your application requirements.
What range does the 201-104 cover?
The Mitutoyo 201-104 covers a 75–100 mm diameter range. The measuring range can be adjusted using the adjustment nut.
What are the benefits of the carbide anvils?
The wide, flat carbide anvils provide stable contact with the workpiece and are designed to withstand repeated contact during production inspection.
What is the anvil retracting stroke?
The Mitutoyo 201-104 has a 2 mm anvil retracting stroke, which helps make inserting and removing workpieces easier.
Which Mitutoyo snap gauge size should I choose?
Choose the snap gauge whose specified range covers the diameter of the parts you need to inspect. The 201-104 covers 75–100 mm, while the Mitutoyo 201-105 covers 100–125 mm.
Is the genuine Mitutoyo 201-104 available in Saudi Arabia?
General Tech Services LLC supplies genuine Mitutoyo products in Saudi Arabia. Contact us for current availability and quotation information for the 201-104.
Request Pricing and Availability
For genuine Mitutoyo 201-104 dial snap gauges in Saudi Arabia, contact General Tech Services LLC for pricing, availability and supply information.
