Mitutoyo 146-125 | Internal Groove Micrometer | 75-100 mm, Rotating Spindle, 12.7 mm Flange
Covering 75-100 mm, the Mitutoyo 146-125 internal groove micrometer has a 12.7 mm flange and rotating spindle for measuring groove width and position in bores. A two-directional ratchet stop is fitted to the 146-125, and the scale reads in 0.01 mm steps.
- Outside range 75-100 mm, 12.7 mm flange, rotating spindle
- Inside range 76.5-101.5 mm (rotating spindle, 12.7 mm flange)
- Spindle pitch 0.5 mm (75-100 mm, rotating spindle)
- Mass 160 g; box and key included (146-125 rotating)
- Specifications
- Features
- Downloads
| Part Number | 146-125 |
| Brand | Mitutoyo |
| Spindle Type | Rotating |
| Flange | 12.7 mm (0.500 in) |
| Range Outside | 75-100 mm |
| Graduation | 0.01 mm |
| Spindle Pitch | 0.5 mm |
| Analogue/Digital | Analogue |
| Mass | 160 g |
| Delivered | Box, key |
| Scale | Satin chrome thimble and sleeve, Ø18 mm |
| Range Inside | 76.5-101.5 mm |
This Internal Groove Micrometer is designed to measure the width and location of grooves cut into bore walls.
It offers the following features:
- Two-directional ratchet stop.
- Non-rotating spindle models are also available.
