Mitutoyo 145-193 Caliper Jaw Inside Micrometer 0.2-1.2"
Part No. 145-193 | Range .2–1.2" | Graduation .001" | Accuracy ±.00025"
Product Overview
The Mitutoyo 145-193 caliper jaw inside micrometer is designed for measuring small internal dimensions such as bore diameters, internal grooves and slot widths across a .2–1.2" range. Its caliper-type jaws allow direct measurement inside features that can be difficult to access with standard outside micrometers.
The jaws are made from high-grade tool steel with carbide-tipped measuring faces for wear resistance during regular inspection work. A locking clamp secures the spindle after measurement, allowing the micrometer to be withdrawn from a bore or groove while retaining the reading.
The satin chrome thimble and sleeve provide an analog .001" graduation, while the fully mechanical design requires no battery. A setting ring or inside setting standard is required to establish the reference before measurement and is available separately.
For larger internal features, see the Mitutoyo 145-194, which covers a 1–2" range.
Key Benefits
-
Measures internal bores, grooves and slots from .2–1.2".
-
±.00025" accuracy with .001" graduation.
-
Carbide-tipped measuring faces provide resistance to measuring-face wear.
-
Caliper-type jaws provide access to difficult internal features.
-
Locking clamp secures the spindle after taking a measurement.
-
Satin chrome thimble and sleeve provide an analog mechanical reading.
-
No battery required.
-
Supplied with a protective case.
Who This Product Is Best For
The Mitutoyo 145-193 is suitable for machine shops, maintenance workshops, hydraulic and pump repair applications, valve manufacturing and dimensional inspection work. It can be used for checking bore diameters, internal grooves and slot widths on components such as bushings, valve bodies, hydraulic fittings and turned parts.
It is particularly useful where a mechanical, battery-free inside micrometer is preferred for routine dimensional inspection.
How to Use
-
Set the micrometer against a setting ring or inside standard of known size before measurement.
-
Adjust the jaws to a position slightly smaller than the feature being measured.
-
Insert the jaws squarely into the bore, groove or slot.
-
Open the jaws gradually until both measuring faces contact the feature.
-
Rock the micrometer slightly to locate the maximum reading where appropriate.
-
Lock the spindle with the clamp and withdraw the tool if required.
-
Read the measurement from the thimble and sleeve.
Frequently Asked Questions
What is the Mitutoyo 145-193 used for?
The Mitutoyo 145-193 is used to measure internal dimensions such as bore diameters, internal grooves and slot widths within its .2–1.2" range.
How accurate is the Mitutoyo 145-193?
The 145-193 has a stated accuracy of ±.00025" and a .001" graduation.
Does the Mitutoyo 145-193 require a setting ring?
Yes. An inside micrometer should be checked and set against a reference of known size before measurement. The required setting ring or inside setting standard is sold separately.
What is the measuring range of the 145-193?
The measuring range is .2–1.2".
Is the Mitutoyo 145-193 digital?
No. The 145-193 is an analog, fully mechanical inside micrometer and does not require a battery.
What is the difference between the 145-193 and 145-194?
The 145-193 covers .2–1.2", while the 145-194 covers 1–2". Select the model according to the internal dimension you need to measure.
Is there a digital Mitutoyo model for the same range?
The Mitutoyo 345-350-30 is a Digimatic caliper-type inside micrometer covering the same .2–1.2" range, with a digital display and SPC data output.
