Mitutoyo 103-150 | Outside Micrometer | 325-350 mm, 0.01 mm graduation
The Mitutoyo 103-150 is a mechanical outside micrometer covering 325-350 mm with 0.01 mm graduation and ±6 µm accuracy. Any part that fits between its anvil and spindle within the 325-350 mm span can be checked for length, thickness or depth in machining and mechanical engineering.
- Measuring range 325-350 mm, graduation 0.01 mm
- Accuracy ±6 µm over the full 325-350 mm travel
- Ratchet stop on the 103-150 for a constant measuring force
- Carbide measuring faces on the 103-150
- Frame of the 103-150 finished in baked enamel
- Setting standard included with the 103-150
- Specifications
- Features
- Downloads
| Part Number | 103-150 |
| Brand | Mitutoyo |
| Type | Mechanical outside micrometer |
| Range | 325-350 mm |
| Graduation | 0.01 mm |
| Accuracy | ±6 µm |
| Frame | Baked-enamel finish |
| Setting Standard | Included |
| Units | Millimetre |
| Measuring Force | Ratchet stop |
| Measuring Faces | Carbide |
Baked-enamel-finished frame.
• Equipped with Ratchet Stop for constant measuring force.
• Measuring faces: carbide.
• Setting standard included on models measuring above 25 mm / 1" maximum measuring range.
