Mitutoyo 1003TB | Dial Indicator | 0-4 mm, 0.01 mm, flat back
The Mitutoyo 1003TB is a Series 1 flat-back dial indicator with a 0-4 mm range, 0.01 mm graduation and ±0.013 mm accuracy. The flat back allows stable mounting on surfaces and fixtures.
- Range 4 mm, graduation 0.01 mm on the 1003TB
- Accuracy ±0.013 mm, repeatability 3 µm, hysteresis 3.5 µm
- Carbide-tipped contact point, M2.5 x 0.45 mm thread
- 8 mm stem, ISO type
- Weight 48 g
- Specifications
- Features
- Downloads
| Part Number | 1003TB |
| Brand | Mitutoyo |
| Series | 1 |
| Type | Dial Indicator, ISO type |
| Range | 4 mm (0.157 in) |
| Graduation | 0.01 mm |
| Hysteresis | 3.5 µm |
| Repeatability | 3 µm |
| Stem Diameter | 8 mm (0.315 in) |
| Back | Flat back |
| Contact Point | Carbide tipped |
| Thread | M2.5 x 0.45 mm |
| Accuracy | ±0.013 mm |
| Weight | 48 g |
- Measuring Range: 0 to 4 mm for general-purpose measurements
- Graduation: 0.01 mm for straightforward, accurate readings
- Accuracy: ±0.013 mm for dependable measurement results
- Mounting: Flat back for stable and flush mounting setups
- Design: Compact and durable for shop or lab environments
- Series: Part of Series 1, known for reliability and ease of use
