ifm SM6100, SM Series Magnetic Inductive Flow Meter Flow Sensor for Liquid, 0.1 l/min Min, 25 L/min Max

Name: ifm SM6100, SM Series Magnetic Inductive Flow Meter Flow Sensor for Liquid, 0.1 l/min Min, 25 L/min Max
Brand: ifm
SKU: SM6100
Availability: OutOfStock

Part Number : SM6100

Availability: Sold out

Detailed Description
Specifications

The ifm electronic Magnetic Inductive Flow Meter is designed for industrial applications, featuring gold plated contacts for enhanced durability. It supports a totalizer function and is suited for measuring conductive liquids, including water and hydrous media. The meter requires a minimum media conductivity of 20 μS/cm and can handle viscosities up to 70 mm²/s at 40°C. It features a minimum insulation resistance of 100 MOhm at 500 V DC and includes reverse polarity protection. The meter has a power on delay time of 5 seconds and employs a magnetic-inductive measuring principle for accurate flow measurement.

Precise measurement of flow
Precise measurement of consumption and medium temperature
High accuracy
High repeatability and measurement dynamics
With switching output
Analogue output and pulse output
Clearly visible 4-digit LED display
Convenient operation via buttons or parameter setting via IO-Link

Brand	ifm
Media Monitored	Liquid
Device Type	Magnetic Inductive Flow Meter
Minimum Flow Rate	0.1 l/min
Maximum Flow Rate	25 L/min
Supply Voltage	30 V
Series	SM
