Dwyer VFC-132-EC | Visi-Float Flowmeter | 200-1400 LPM Air, 1" female NPT
The Dwyer VFC-132-EC is a Visi-Float® VFC flowmeter scaled 200-1400 LPM for air, with 1" female NPT PVC back connections. Its clear acrylic body and machined scale let you read air flow directly, and the VFC design suits liquid or gas lines.
- Accuracy of 2% of full scale
- 5" (127 mm) typical scale length
- Stainless steel float and metal parts
- Buna-N O-ring, fluoroelastomer available
- Mounts in the vertical position
- Weight 24 to 25 oz (0.68 to 0.71 kg)
- Specifications
- Features
- Downloads
| Part Number | VFC-132-EC |
| Brand | Dwyer |
| Series | Visi-Float® VFC |
| Accuracy | 2% of FS |
| Weight | 24 to 25 oz (0.68 to 0.71 kg) |
| Process Connection | 1" female NPT back connections (end connections optional) |
| Approvals | RoHS II (EU Directive 2011/65/EU) |
| Mounting | Vertical |
| Range | 200-1400 LPM air |
| Scale Length | 5" (127 mm) typical |
| Body Material | Acrylic plastic |
| Float | Stainless steel |
| Fittings | Pvc |
| O-Ring | Buna-N (fluoroelastomer available) |
- Solid, transparent acrylic blocks are used for the body's cutting and precise machining, enabling thorough visual examination.
- The float is easier to see on a white background, which improves reading accuracy.
- The material has direct reading scales hot stamped onto it, extending the life of the product and removing the need for laborious conversions.
- A very repeatable tapered bore made by precision machining is possible.
- Minimal installation expenses with options for end or back connections.
