Dwyer Instruments RMB-51D | Flowmeter | Range 2-20 SCFH/1-9.5 LPM air - generaltechuae

Dwyer RMB-51D | Rate-Master Flowmeter | 2-20 SCFH (1-9.5 LPM) Air, 5" Scale, No Valve

Part Number : RMB-51D

Built without a valve, the Dwyer RMB-51D Rate-Master flowmeter gives a direct reading of 2-20 SCFH (1-9.5 LPM) air across a 5" (127 mm) scale. Use the RMB-51D for general-purpose gas or liquid flow monitoring, either surface mounted or set into a panel.

  • Range 2-20 SCFH (1-9.5 LPM) air on the 5" (127 mm) scale, no valve fitted
  • 3% accuracy and 1/4" female NPT process connections on the RMB-51D
  • RMB-51D rated to 100 psi (6.9 bar) and 130°F (54°C) maximum operating conditions
  • Wetted parts of the RMB-51D: polycarbonate body, Neoprene/Buna-N O-rings, stainless steel metal parts
  • RMB-51D body swaps within its 5" scale size for cleaning or a range change, leaving pipework in place
  • Weighs 13 oz (368.5 g); the RMB-51D meets RoHS II (EU Directive 2011/65/EU)
Availability: in stock
Free Saudi Arabia shipping available
For pricing, please contact our experts.
