Dwyer RHP-3D3E | Duct Humidity/Temperature Transmitter | ±3% RH, 0-5 V RH, Pt1000 RTD
Part Number : RHP-3D3E
With a 0-5 V humidity output plus a passive Pt1000 RTD temperature output, the Dwyer RHP-3D3E is a duct-mount unit measuring humidity to ±3% (20 to 80% RH @ 25°C). This Series RHP model, RHP-3D3E, senses humidity with a capacitance polymer element.
- Supply for the 0-5 V version: 15-35 VDC or 15-29 VAC
- Pt1000 RTD temperature sensor: DIN Class B, ±0.3°C @ 0°C (±0.54°F @ 32°F) on the RHP-3D3E
- Measures 0 to 100% RH; drift below 1% RH per year, hysteresis ±1%, response time 15 s (RHP-3D3E)
- RHP-3D3E: Duct mount: NEMA 4X (IP66) housing, 1/2" NPS conduit connection, 0.616 lb (0.3 kg)
- Operating range -40 to 140°F (-40 to 60°C) on the RHP-3D3E
