Dwyer RHP-3D2D | Duct Humidity/Temperature Transmitter | ±3% RH, 0-10 VDC RH, 100 Ω RTD
Part Number : RHP-3D2D
The Dwyer RHP-3D2D gives a 0-10 VDC humidity output plus a passive 100 Ω RTD (DIN 385) temperature output from a duct-mount housing, with humidity accuracy of ±3% (20 to 80% RH @ 25°C). The RHP-3D2D belongs to Series RHP and uses a capacitance polymer humidity sensor.
- RHP-3D2D: Supply for the 0-10 VDC version: 15-35 VDC or 15-29 VAC
- 100 Ω RTD temperature sensor: DIN Class B, ±0.3°C @ 0°C (±0.54°F @ 32°F) on the RHP-3D2D
- Measures 0 to 100% RH; drift below 1% RH per year, hysteresis ±1%, response time 15 s (RHP-3D2D)
- RHP-3D2D: Duct mount: NEMA 4X (IP66) housing, 1/2" NPS conduit connection, 0.616 lb (0.3 kg)
- Operating range -40 to 140°F (-40 to 60°C) on the RHP-3D2D
