Dwyer RHP-2D1D | Duct Mount RH/Temperature Transmitter | 2% RH, 4-20 mA RH, 100 Ohm RTD Curve D Output
The Dwyer RHP-2D1D is a 2% duct mount RH/temperature transmitter with a 4-20 mA humidity output and a 100 Ohm RTD Curve D temperature output. This 4-20 mA, 100 Ohm RTD Curve D version is loop powered from 10-35 VDC and uses a capacitance polymer sensing element with a 15 second response.
- 4-20 mA RH output
- 100 Ohm RTD Curve D temperature output
- Power 10-35 VDC (loop powered); long-term drift <1% RH per year
- Responds in 15 s with ±1% hysteresis
- IP66 / NEMA 4X housing
- Specifications
- Features
- Downloads
| Part Number | RHP-2D1D |
| Brand | Dwyer |
| Power | 10-35 VDC (loop powered) |
| Response Time | 15 s |
| Drift | <1% RH/year |
| Mounting | Duct |
| Temperature Output | 100 Ohm RTD Curve D (passive) |
| Enclosure Rating | NEMA 4X (IP66), housing |
| Output | 4-20 mA (RH) |
| Approvals | CE |
| RH Accuracy Class | 2% |
| Sensor | Capacitance polymer |
| Compensated Range | -4 to 140 °F (-20 to 60 °C) |
- Lower installation costs when temperature and humidity are combined.
- With 2%, 3%, and 5% accuracy and a wide range of temperature sensors, there is a wide application environment.
- Lower system operating costs thanks to the radiation barrier that shields the sensor from heat radiation.
