Dwyer RHP-2D10 | Duct Mount Humidity Transmitter | 2% RH, 4-20 mA RH Output
With a 4-20 mA RH signal, the Dwyer RHP-2D10 is a 2% duct mount humidity transmitter. The RH-only build with 4-20 mA output wires to a removable screw terminal block and is loop powered from 10-35 VDC, with drift below 1% RH per year.
- Compensation range -4 to 140°F
- Screw terminal block that unplugs for wiring
- CE approved
- RH transmitted as 4-20 mA
- RH-only model
- Supply 10-35 VDC (loop powered)
- Specifications
- Features
- Downloads
| Part Number | RHP-2D10 |
| Brand | Dwyer |
| Power | 10-35 VDC (loop powered) |
| Response Time | 15 s |
| Drift | <1% RH/year |
| Mounting | Duct |
| Enclosure Rating | NEMA 4X (IP66), housing |
| Output | 4-20 mA (RH) |
| Approvals | CE |
| RH Accuracy Class | 2% |
| Sensor | Capacitance polymer |
| Compensated Range | -4 to 140 °F (-20 to 60 °C) |
- Lower installation costs when temperature and humidity are combined.
- With 2%, 3%, and 5% accuracy and a wide range of temperature sensors, there is a wide application environment.
- Lower system operating costs thanks to the radiation barrier that shields the sensor from heat radiation.
