Dwyer PV33 | Solenoid Pilot Valve | 24 VAC, for 3-9/16" SAV Actuator
Part Number : PV33
Dwyer's PV33 pilots 3-9/16" Series SAV angle seat valve actuators from a 24 VAC signal. This three-way, normally closed electro-pneumatic valve moves the actuator when energised and blocks the pneumatic supply again when de-energised, letting the PV33 return the valve to its usual state.
- PV33 pilot media: air, water or inert gases (water needs a drain line on the exhaust)
- IP65 with the supplied DIN connector; manual override on the PV33
- Niploy-coated brass body with FKM seal; the PV33 mounts by banjo connection
- PV33 ratings: 150 psig (10.3 bar), -10 to 60°C
- PV33 coil voltage: 24 VAC
Free Saudi Arabia shipping available
For pricing, please contact our experts.
