Dwyer PV12 | Solenoid Pilot Valve | 120 VAC, for 1-3/4" SAV Actuator
Part Number : PV12
The Dwyer PV12 is a three-way, normally closed electro-pneumatic solenoid pilot valve powered at 120 VAC and sized for 1-3/4" diameter Series SAV angle seat valve actuators, onto which it mounts directly. When the PV12 coil is energised it drives the actuator open (or closed on normally open valves); removing the signal blocks the supply pressure again.
- PV12 coil voltage: 120 VAC
- Actuator port 1/8" BSP and 1/8" NPT pilot media port on the PV12
- PV12 pilot media: air, water or inert gases (water needs a drain line on the exhaust)
- IP65 with the supplied DIN connector; manual override on the PV12
- Niploy-coated brass body with FKM seal; the PV12 mounts by banjo connection
