Dwyer Instruments HBV-M08 | 2" 3-piece alloy-c ball valve | Cv 400
The Dwyer HBV-M08 is a 2" NPT, 3-piece Hastelloy C ball valve designed for demanding high-pressure and corrosive-service applications. Manufactured from ASTM A494 Type CW12MW Hastelloy C, it provides a corrosion-resistant solution for chemical process lines and other applications where standard stainless steel may not be suitable.
The valve features an ISO 5211 actuator mounting pad for direct installation of pneumatic or electric actuators, making it suitable for automated process isolation. Its 3-piece construction supports in-line servicing without requiring removal of the entire valve from the pipe run.
Part Number: HBV-M08
The Dwyer HBV-M08 is a high-performance 3-piece ball valve designed for demanding process applications involving corrosive media, high pressure, and elevated temperatures. Its body is machined from ASTM A494 Type CW12MW Hastelloy C, a material selected for demanding chemical process environments where corrosion resistance is critical.
The 2" NPT female connections provide a threaded installation for compatible process piping. The 3-piece body construction allows in-line servicing without requiring the valve to be completely removed from the pipe run, helping simplify maintenance procedures.
For automated applications, the HBV-M08 incorporates an ISO 5211 actuator mounting pad. This allows compatible pneumatic or electric actuators to be mounted directly to the valve. The high-cycle, live-loaded stem packing system is designed to maintain sealing through repeated operation, while the non-blowout stem includes lockout capability for safe isolation.
With a Cv of 400, a maximum pressure rating of 2000 psi (137.9 bar) under ASME B16.34 Class 900, and a maximum operating temperature of 425°F (218°C), the HBV-M08 is designed for demanding corrosive and high-temperature process service.
For a smaller valve in the same range, the Dwyer HBV-M07 provides a 1-1/2" NPT configuration with a Cv of 120.
Key Benefits
- 2" NPT female connections
- Hastelloy C body manufactured from ASTM A494 Type CW12MW
- 3-piece construction for in-line servicing
- ISO 5211 actuator mounting pad
- Compatible with pneumatic or electric actuator automation
- High-cycle, live-loaded stem packing
- Non-blowout stem with lockout capability
- Cv of 400
- Maximum pressure rating of 2000 psi (137.9 bar)
- ASME B16.34 Class 900 pressure rating
- Maximum operating temperature of 425°F (218°C)
- Suitable for demanding corrosive and high-temperature process applications
Who This Product Is Best For
The Dwyer HBV-M08 is suitable for process engineers, chemical processing facilities, automation specialists, and controls contractors who require a corrosion-resistant, automation-ready ball valve for 2" NPT process lines.
It is particularly suited to applications involving corrosive process media, high-pressure service, elevated temperatures, and automated process isolation.
How to Use
- Install the HBV-M08 at the required process isolation point in the 2" NPT line.
- Ensure the valve and piping connections are correctly installed and suitable for the intended process conditions.
- If automation is required, mount a compatible pneumatic or electric actuator to the ISO 5211 mounting pad.
- Commission the actuator, if fitted, and verify smooth open/close operation before starting the process.
Frequently Asked Questions
What is the HBV-M08 body made of?
The HBV-M08 body is made from ASTM A494 Type CW12MW Hastelloy C for demanding corrosive process applications.
What is the Cv of the HBV-M08?
The HBV-M08 has a Cv (flow coefficient) of 400.
Can the HBV-M08 be automated?
Yes. The valve features an ISO 5211 actuator mounting pad for direct mounting of compatible pneumatic or electric actuators.
What is the maximum pressure rating of the HBV-M08?
The maximum pressure rating is 2000 psi (137.9 bar), in accordance with ASME B16.34 Class 900.
What is the maximum operating temperature?
The maximum operating temperature is 425°F (218°C).
What type of valve construction does the HBV-M08 use?
The HBV-M08 uses a 3-piece ball valve construction, allowing in-line servicing without removing the entire valve from the pipe run.
Does GeneralTech Shop deliver the HBV-M08 across the UAE?
Contact GeneralTech Shop at +971 6 5436933 to confirm availability and delivery timelines for your emirate.
What is the difference between the HBV-M08 and HBV-M07?
The HBV-M08 is a 2" NPT valve with a Cv of 400, while the HBV-M07 is the adjacent smaller model with a 1-1/2" NPT connection and a Cv of 120. Both are part of the same Alloy-C ball valve range.
