Dwyer DFMT2-10A | Remote Digital Flow Transmitter | 3/8" NPT, 4-20 mA/Pulse
The Dwyer DFMT2-10A is a two-piece remote paddlewheel flow transmitter with a 3/8" NPT process connection. Separating the display unit from the sensor suits tight spaces such as reverse osmosis water purification systems. Its large backlit display has an easy menu, and a security password can lock the settings.
- 3/8" NPT PVDF sensor and impeller
- Selectable 4-20 mA or pulse output
- Instantaneous and totalised flow, totaliser resettable
- Password protection for settings
- Accuracy ±1.5% FS; repeatability ±0.5% FS
- Remote two-piece build for 3/8" NPT installations where panel space is tight
- Specifications
- Features
- Downloads
| Part Number | DFMT2-10A |
| Brand | Dwyer |
| Type | Remote digital flow transmitter (two-piece) |
| Accuracy | ±1.5% FS |
| Process Connection | 3/8" NPT |
| Display | LCD 2.38 x 1.25" (60.33 x 31.75 mm) |
| Wetted Materials | PVDF sensor and impeller, ceramic shaft, fluoroelastomer o-rings |
| Power | 12 to 24 VDC, 2 W |
| Output | 4-20 mA or pulse (user selectable) |
| Repeatability | ±0.5% FS |
| Max. Operating Pressure | 145 psi (1.0 MPa) |
| Process Temperature | -4 to 194 °F (-20 to 90 °C) |
| Enclosure | ABS plastic, IP65 |
| Totaliser Maximum | 9,999,999,999 |
- Because of its two-piece form, which enables the user to divide the control display from the application, it is perfect for spaces with limited space.
- With a visible indicator bar indicating the percentage of maximum flow, the sizable backlit LCD display specifies both immediate and cumulative flow.
- Long operational life, corrosion-resistant PVDF sensor, and high precision paddlewheel technology.
- The user-resettable totalizer makes it perfect for totalizing a single batch at any moment.
- Unauthorized alterations are prevented via security password protection.
