Dwyer Instruments CDT-2E40-LCD | Carbon Dioxide | Wall Mount | Universal current/voltage output | European Housing | LCD Display
The Dwyer CDT-2E40-LCD is a wall-mount carbon dioxide transmitter with a European housing, a 0-2000 ppm CO₂ range, universal 4-20 mA, 0-5 VDC or 0-10 VDC output and an integral LCD display. This model is dedicated to CO₂ measurement and does not provide a temperature output, making it suitable for indoor CO₂ monitoring, demand-controlled ventilation and building automation applications. Genuine stock at General Tech Services LLC, UAE, with free UAE-wide shipping. Request a quote in under a minute - call +971 6 5436933.
Part No. CDT-2E40-LCD
Product Overview
The Dwyer Series CDT Carbon Dioxide Transmitters accurately monitor CO₂ concentration in indoor environments to support ventilation control and energy-saving applications. The CDT-2E40-LCD is a wall-mount European housing model with a 0-2000 ppm CO₂ range, no temperature output and an integral LCD display.
A single-beam, dual-wavelength NDIR sensor automatically compensates for light-source aging effects in occupied and unoccupied buildings. The transmitter includes digital barometric pressure adjustment and field calibration capability. Its universal CO₂ output can be configured for 4-20 mA, 0-5 VDC or 0-10 VDC to suit the connected controller.
Push buttons provide access to the menu structure, while an internal DIP switch can lock the menu to help prevent unwanted changes. The backplate electrical connection simplifies installation.
The CDT-2E40 is the same transmitter without the integral LCD display.
Key Benefits
- Dedicated 0-2000 ppm CO₂ measurement
- Single-beam, dual-wavelength NDIR sensor with 15-year life expectancy
- Universal 4-20 mA, 0-5 VDC or 0-10 VDC CO₂ output
- Integral LCD display for local CO₂ monitoring
- Digital barometric pressure adjustment
- Field calibration capability
- Lockable push-button menu access
- European wall-mount housing
- Backplate electrical connection for simplified installation
- CDT-2E40 available without the integral LCD display
- Genuine Dwyer stock with free UAE-wide shipping
Who This Product Is Best For
- Demand-controlled ventilation in schools, offices, hospitals and commercial buildings
- HVAC and building automation systems requiring dedicated CO₂ monitoring
- Projects specifying European wall-mount CO₂ sensing
- Applications requiring universal analog CO₂ outputs
- LEED-driven ventilation monitoring projects
- Installations requiring local CO₂ readings through an integral LCD display
- Applications where temperature measurement is not required
How to Specify & Commission It
- Confirm the 0-2000 ppm CO₂ range, dedicated CO₂ measurement and European wall-mount housing are suitable for the application.
- Mount the transmitter according to the installation requirements.
- Wire the power supply and select the required 4-20 mA, 0-5 VDC or 0-10 VDC CO₂ output.
- Set the barometric pressure and perform field calibration if required.
- Configure the menu and lock it with the internal DIP switch if required.
- Verify the CO₂ reading at the connected controller and confirm the LCD display operates correctly.
Frequently Asked Questions
What does the CDT-2E40-LCD measure?
It measures CO₂ from 0-2000 ppm only. This model does not provide a temperature output.
What CO₂ outputs are available?
The universal CO₂ output can be configured for 4-20 mA, 0-5 VDC or 0-10 VDC.
How accurate is the CDT-2E40-LCD?
CO₂ accuracy is ±40 ppm + 3% of reading at 2000 ppm.
What sensor technology is used?
It uses a single-beam, dual-wavelength NDIR sensor with a 15-year life expectancy.
Does the CDT-2E40-LCD have an LCD display?
Yes. This model has an integral LCD display for local CO₂ monitoring.
Is the CDT-2E40-LCD wall or duct mounted?
It is a wall-mount model with a European housing.
Can the transmitter be field calibrated?
Yes. The CDT series provides field calibration capability and digital barometric pressure adjustment.
Is a non-LCD version available?
Yes. The CDT-2E40 is the same dedicated CO₂ transmitter without the integral LCD display.
Is genuine stock available with UAE shipping?
Yes. Genuine Dwyer stock is available through General Tech Services LLC with free UAE-wide shipping. Call +971 6 5436933 for pricing and current availability.
