Dwyer AFS-142 | Adjustable Flow Switch | for water, polysulfone piston, conduit
Designed for water, the Dwyer AFS-142 adjustable flow switch uses a polysulfone piston in a brass housing. Set point adjustment on this unit spans 0.5 to 20 GPM (1.9 to 75.7 LPM), with 1/2" NPT conduit connection for wiring.
- SPDT switch rated .17 A @ 120 VAC, .13 A @ 120 VDC on the AFS-142
- AFS-142 accuracy ±10% of set point, repeatability ±1%
- 1/2" female NPT ports; AFS-142 rated to 1000 psi (68 bar)
- AFS-142 temperature range -20 to 225°F (-29 to 107.2°C)
- Any mounting position; filtration of 50 microns or better recommended for the AFS-142
- Specifications
- Features
- Downloads
| Part Number | AFS-142 |
| Brand | Dwyer |
| Product Type | Adjustable flow switch |
| Process Connection | 1/2" female NPT |
| Switch Type | SPDT |
| Maximum Pressure | 1000 psi (68 bar) |
| Electrical Connection | 1/2" NPT conduit connection |
| Temperature Range | -20 to 225 °F (-29 to 107.2 °C) |
| Accuracy | ±10% of set point |
| Required Filtration | 50 microns or better |
| Medium | Water |
| Set Point Adjustment | 0.5 to 20 GPM (1.9 to 75.7 LPM) |
| Piston Material | Polysulfone |
| Housing Material | Brass |
- Flow set point that is modifiable externally.
- Provides a range of flow settings with accurate repeatability and minimal pressure drop at pressures up to 1000 psig.
