Dwyer 246 | Inclined Stationary Manometer | 0-6" w.c., 20" Scale
Spanning 0-6" w.c. across a 20" inclined scale, the Dwyer 246 is the largest Series 200 Durablock stationary gage in this set, for precise low-pressure work.
- Range 0-6" w.c., .02" minor divisions
- 20" inclined scale on the 246, accuracy ±1%
- Precision-machined acrylic bore and well on the 246
- Weighs 13 lb 14 oz, maximum operating temperature 150 °F
- Specifications
- Features
- Downloads
| Part Number | 246 |
| Brand | Dwyer |
| Series | Series 200 Durablock |
| Type | Inclined Tube Manometer |
| Range | 0-6" w.c. |
| Accuracy | ±1% |
| Weight | 13 lb 14 oz |
| Minor Division | .02" |
| Scale Length | 20" |
| Maximum Operating Temperature | 150 °F |
- Sturdy plastic fixed gauge,.02 minor division, 0–6" w.c., 20" scale, 13 lb 14 oz 1" thick acrylic The body is a single, nearly indestructible block that is stable and free from distortion risk.
- Without any kinks or dents, the drilled bore is accurate to ±.0002" and won't need to be recalibrated due to distortion.
- For the most precise readability, a consistent, well-shaped meniscus is formed by carefully choosing gauge fluid with good wetability qualities.
- Easily zero in with these polished aluminum adjustable reflective scales that lock with a thumbscrew.
- To get optimal precision and consistency in parallax-free reading, just align the meniscus with the picture reflected in the scale.
- Over-Pressure Safety Traps stop fluid loss brought on by pressure surges or over-range pressures.
- For inclined style gauges, leveling adjustment is as easy as removing a locking thumb screw located on the gage's side or bottom and adjusting in relation to the integral.
