Dwyer 215 | Inclined Stationary Manometer | .05-0-.25" w.c., 6" Scale
For the finest readings in this group, the Dwyer 215 Durablock inclined gage spans .05-0-.25" w.c. with .005" minor divisions on a 6" scale.
- Range .05-0-.25" w.c., .005" minor divisions
- 6" inclined scale on the 215, accuracy ±1%
- Precision-machined acrylic bore and well on the 215
- Weighs 2 lb 14 oz, maximum operating temperature 150 °F
- Specifications
- Features
- Downloads
| Part Number | 215 |
| Brand | Dwyer |
| Series | Series 200 Durablock |
| Type | Inclined Tube Manometer |
| Range | .05-0-.25" w.c. |
| Accuracy | ±1% |
| Weight | 2 lb 14 oz |
| Minor Division | .005" |
| Scale Length | 6" |
| Maximum Operating Temperature | 150 °F |
- Sensitivity range:.05-0-.25" w.c.,.005 minor division, 6" scale, weight: 2 lbs., 14 oz.
- 1" Thick Acrylic Plastic The body is a single, nearly indestructible block that is stable and free from distortion risk.
- Without any kinks or dents, the drilled bore is accurate to ±.0002" and won't need to be recalibrated due to distortion.
- Particular Gauge For the most precise readability, a fluid with good wetability properties generates a consistent, well-shaped meniscus.
- Easily zero in with these polished aluminum adjustable reflective scales that lock with a thumbscrew.
- To get optimal precision and consistency in parallax-free reading, just align the meniscus with the picture reflected in the scale.
- Over-Pressure Protection Traps stop fluid loss brought on by pressure surges or over range pressures.
- For inclined style gauges, leveling adjustment is as easy as removing a locking thumb screw located on the gage's side or bottom and adjusting in relation to the integral.
