Dwyer 115 | Portable Inclined Manometer | .05-0-.25" w.c., .005" Divisions, 6" Scale
Reading .05-0-.25 in w.c. with .005 in minor divisions, the Dwyer 115 is an inclined-tube Durablock portable manometer with a 6 in scale. Use it to measure static pressure, vacuum or differential pressure; a plastic carrying case is included.
- Range .05-0-.25 in w.c., graduated in .005 in minor divisions
- 6 in scale length on the 115
- 115 uses inclined-tube construction in solid plastic
- Plastic carrying case supplied with the 115
- Acrylic bore and well machined to close tolerances (115)
- Specifications
- Features
- Downloads
| Part Number | 115 |
| Brand | Dwyer |
| Series | 100 Durablock |
| Type | Inclined tube |
| Range | .05-0-.25" w.c. |
| Weight | 3 lb 10 oz |
| Scale Length | 6" |
| Measurement | Differential, vacuum |
| Minor Divisions | .005" |
| Carrying Case | Plastic |
- Portable solid plastic gauge with a.05-0-.25" w.c. range,.005 minor division, a 6" scale, and a plastic carrying box.
- The 1" Thick Acrylic Plastic Body is a robust, nearly indestructible block that is not susceptible to distortion.
- The precision of the drilled bore, which is accurate to ±.0002", is unaffected by bends or curves and doesn't need to be adjusted due to distortion.
- High wetability gauge oil is chosen to create a well-shaped, constant meniscus that is easy to read.
- Easy zeroing is made simple with the thumbscrew locking adjustable reflective chrome finish scales.
- To ensure optimal precision and consistency in parallax-free reading, just line the meniscus with its reflected image in the polished metal scale.
- With reference to an integrated sensitive ground glass bubble level, the screw type leveling adjustment for inclined style gauges offers quick and precise leveling.
- Fully equipped with extras and a carrying case made of plastic.
