DMQ QH5 U | Portable UCI Hardness Tester | 10/50/98 N UCI probes, HV 100–950
The DMQ QH5 U uses the UCI (ultrasonic contact impedance) method instead of Leeb rebound, which suits small and thin parts, surface treatments and weld heat-affected zones. It accepts 10 N, 50 N and 98 N UCI probes with CalTag calibration and is supplied with a UCI probe and an HV reference test block.
Key features
- UCI method, range HV 100–950
- Accuracy ±5% across the HV range
- Works with 10 N, 50 N and 98 N CalTag UCI probes
- Reads HV, HRC, HRB, HB, HS and N/mm², plus user units
- 32,000-reading memory with USB transfer to dmq DataCenter
- CE marked; ASTM A1038 and ASTM E140
The QH5 U ships in a high-impact carrying case containing the electronic unit, a UCI probe, an HV reference test block, a USB cable, coupling paste, a pendrive with dmq DataCenter, a printed user manual and a certificate of conformity.
- Specifications
- Features
- Downloads
| Part Number | QH5 U |
| Brand | DMQ |
| Accuracy | ±5% (HV range) |
| Standards | CE, ASTM A1038, ASTM E140 |
| Method | UCI |
| Memory | 32,000 readings |
| Power | 2 x AA |
| Battery Life | 150 h approx. (no light) |
| Dimensions | 79 x 117 x 32 mm (3.11×4.61×1.26 in) |
| Range | HV 100–950 |
| Weight | 182 g |
| Probes | 10 N, 50 N, 98 N UCI |
| Materials | Steel, aluminium, copper, brass |
- Automatic hardness unit conversions
- User defined units
- Direct access key
- Realtime graphics
- Realtime statistics
- Alarms
- Selectable view modes
- Measuring modes
- Internal clock
