Desoutter DR300-T2000-C8 | Pneumatic Straight Drill with Keyed Chuck | 2000 rpm, 5.4 Nm, 8 mm Chuck
Running at 2000 rpm free speed with 5.4 Nm (4 ft.lbf) stall torque, the Desoutter DR300-T2000-C8 (6151760570) is a pneumatic straight drill with keyed chuck from the DR300 range. The inline DR300-T2000-C8 is fitted with a keyed chuck for bits up to 8 mm (5/16 in) on a 3/8-24 mount, with a length of 206 mm (8.11 in) and a weight of 0.49 kg (1.08 lb). Built on the 300 W DR300 platform, the DR300-T2000-C8 is aimed at standard drilling work where repeatability and low noise matter.
Key features
- Safety lever start and progressive trigger for controlled hole starts (DR300-T2000-C8)
- Long-life gears and a 5 blade air motor drive the DR300-T2000-C8
- The DR300-T2000-C8 has an aluminium body, composite over-sleeve and soft rubber grip
- 9.5 l/s (20 cfm) air consumption at free speed through a 1/4 in inlet; minimum hose 6 mm for 5 m (DR300-T2000-C8)
- Specifications
- Downloads
| Part Number | 6151760570 |
| Model | DR300-T2000-C8 |
| Brand | Desoutter |
| Tool type | Inline |
| Free Speed | 2000 rpm |
| Stall torque | 5.4 Nm (4 ft.lbf) |
| Output type | Output for chuck |
| Chuck type | Keyed |
| Chuck max capacity (mm) | 8 |
| Chuck mount | 3/8-24 |
| Length (L) | 206 mm (8.11 in) |
| Weight | 0.49 kg (1.08 lb) |
| Air consumption at free speed | 9.5 l/s (20 cfm) |
| Starting system | Safety lever |
