DeFelsko UTGCA1 PosiTector UTG CA

DeFelsko UTGCA1 | PosiTector UTG CA Ultrasonic Thickness Gauge, Standard

Part Number : UTGCA1

The DeFelsko UTGCA1 is the PosiTector UTG CA ultrasonic wall thickness gauge on the Standard gage body, using a 5 MHz dual element transducer (built-in (integral) probe). It is aimed at heavily corroded or eroded metal, letting inspectors measure wall thickness from one side of a part or structure.

Key features

  • Probe type: 5 MHz dual element
  • Thru-paint capability: No
  • Measuring Range: 1.00 – 125.00 mm (0.040 – 5.000 in)
  • Accuracy ±0.03 mm (±0.001 in)
  • Pre-programmed sound velocities for common materials; Min Scan mode records min/max thickness
  • Standard gage body stores 1,000 readings per probe
Availability: in stock
For pricing, please contact our experts.
