Dakota Z-306-0003 | ZX6-DL Thickness Gauge | Pulse-Echo & Through Paint
Part Number : Z-306-0003
The Dakota ZX6-DL (ZX-6DL), part number Z-306-0003, is the top model of the ZX basic thickness gauge line. It pairs a standard pulse-echo mode for flaw and pit detection with a multi-echo through paint mode, so material under epoxy-based coatings can be measured without removing the coating.
Gain is adjustable, and automatic time dependent gain works in both measurement modes. Typical uses include tanks, boilers, tube and pipe.
Key features
- Pulse-echo and multi-echo through paint modes
- Adjustable gain with automatic time dependent gain
- Dual element transducers, 1 - 10 MHz, with automatic V-path correction
- 0.01 mm resolution on a 12.7 mm 4.5 digit LCD
- Operates from -30 to 75 °C
- Runs on 2 x AA batteries, about 45 hours on alkaline
For pricing, please contact our experts.
