Brannan 10/910/0 | S Series Specific Gravity Hydrometer | 1.15 to 1.20 SG, 190 mm
Brannan part 10/910/0 covers 1.15 to 1.20 SG as part of the S series of 190 mm general purpose specific gravity hydrometers. Checking liquids denser than water between 1.15 and 1.20 SG, the 10/910/0 has 0.002 SG graduations over its 0.05 SG span. Its 1.15–1.20 SG scale is adjusted at 60 °F (15.6 °C) and compares the liquid with water on the 60/60 °F basis.
Key features
- 1.15–1.20 SG specific gravity range
- 190 mm overall length, 18–20 mm bulb
- Soda glass construction, steel shot ballast
- Adjustment temperature 60 °F (15.6 °C)
- Made in UK, stored in a resealable plastic tube
Certification for the 10/910/0 is available as UKAS, traceable to a recognised national standard, or as a Statement of Conformity.
- Specifications
- Downloads
| Part Number | 10/910/0 |
| Brand | Brannan |
| Series | S series (S50) |
| Range | 1.15 to 1.20 SG |
| Range Span | 0.050 SG |
| Divisions | 0.002 SG |
| Scale | Specific gravity 60/60 °F |
| Adjusted At | 60 °F (15.6 °C) |
| Overall Length | 190 mm |
| Bulb Diameter | 18 to 20 mm |
| Approx. Weight | 35 g (incl. 9 g plastic tube) |
| Material | Soda glass, steel shot ballast, synthetic wax resin |
| Packaging | Resealable plastic tube |
| Country of Manufacture | UK |
