Barton 7106 RF meter, meter Size :6 inch,End Connection Size :1 inch,Flow Rate :250-2500 US GPM

Genuine Barton 7106 turbine flow meter from General Tech Services LLC, Saudi Arabia, with free Saudi Arabia shipping available.

Part No. 7106

Product Overview

The Barton 7106 is a 6-inch liquid turbine flow meter from Cameron BARTON Series 7000, designed for precise measurement of liquid flow in hydrocarbon applications. It covers a flow range of 250–2,500 US GPM and uses a turbine rotor whose rotational speed corresponds to the liquid flow rate.

Liquid enters the meter through a diffuser and passes across the multi-blade turbine rotor. A pickup senses the turbine blade tips and generates a sine-wave signal proportional to flow. This output can be used with compatible preamplifiers, digital readouts, totalizers and flow computers.

The Barton 7106 provides listed linearity of ±0.25% of reading over the flow range, with ±0.15% over limited ranges, and repeatability of ±0.02% of reading. Its symmetrical, bidirectional design supports reverse-flow applications without reducing the stated accuracy or capacity.

The supplied product information lists a 6-inch meter size and a 1-inch end connection size. Series 7000 configurations are available with flanged and threaded connections, so the exact connection arrangement should be confirmed before ordering.

The listed application is hydrocarbon measurement. Typical uses include crude and refined product lines, loading and transfer skids, chemical injection and allocation metering. Matching accessories such as meter runs, preamplifiers, totalizers, connectors and cables are also available.

Before ordering, confirm that normal and maximum flow requirements fall within the meter's range. Also confirm the line size, end-connection style, fluid, pressure rating and electronics that will be connected to the pickup.

Key Benefits

• 6-inch turbine flow meter covering 250–2,500 US GPM
• ±0.25% of reading linearity over the stated flow range
• ±0.15% linearity over limited ranges
• ±0.02% repeatability
• Symmetrical design for bidirectional flow measurement
• Sine-wave pickup output for compatible measurement electronics
• Suitable for digital readouts, totalizers and flow computers
• Cameron BARTON Series 7000 turbine-meter design
• Suitable for hydrocarbon measurement applications
• Free Saudi Arabia shipping available

Who This Product Is Best For

The Barton 7106 is suited to:

• Oil and gas metering and allocation teams
• Terminal, loading and product-transfer operations
• Hydrocarbon measurement applications
• Process and instrumentation engineers
• Flow-meter maintenance and replacement projects
• Teams integrating turbine-meter output with totalizers or flow computers
• Buyers in Saudi Arabia requiring genuine Barton flow measurement equipment

How to Install & Use It

1. Confirm that the meter's flow range, line size and fluid are suitable for the application.
2. Verify the required end-connection arrangement and pressure rating before installation.
3. Install the meter using the recommended upstream and downstream straight-pipe arrangement for the Series 7000 installation.
4. Install a suitable strainer where debris in the liquid could affect the meter or turbine.
5. Connect the pickup to the compatible preamplifier, totalizer, digital readout or flow computer.
6. Enter the applicable meter K-factor into the connected electronics.
7. Fill the line gradually and check the flow indication at normal operating conditions.
8. Verify the output and recorded flow against the commissioning requirements for the installation.

Frequently Asked Questions

What flow range does the Barton 7106 turbine flow meter cover?

The Barton 7106 covers 250–2,500 US GPM in a 6-inch meter size.

How accurate is the Barton 7106?

The listed linearity is ±0.25% of reading over the flow range, with ±0.15% over limited ranges. Repeatability is listed as ±0.02% of reading.

Can the Barton 7106 measure reverse flow?

Yes. The symmetrical Series 7000 design supports reverse-flow applications without reducing the stated accuracy or capacity.

What output does the meter provide?

The pickup produces a sine-wave signal proportional to flow. This signal can be connected to compatible preamplifiers, totalizers, digital readouts or flow computers.

What is the Barton 7106 used for?

The supplied application is hydrocarbon measurement. Typical uses include crude and refined product lines, loading and transfer systems, chemical injection and allocation metering.

What connection options are available?

The supplied Series 7000 information references flanged and threaded end connections. The Barton 7106 listing specifies a 1-inch end connection size, so the exact connection configuration should be confirmed before ordering.

What information should I provide when requesting a quote?

Provide the model number, quantity and delivery city, together with the fluid, required flow range, line size, pressure rating and connection requirements. This helps confirm the appropriate configuration.

How much does the Barton 7106 cost?

Pricing is quote-based. Call +966 569 289 544 for current pricing and lead-time information.
