AVENTICS 1322502000 | ICM Double-Acting Roundline Cylinder | 25 mm Bore, 25 mm Stroke
Part Number : 1322502000
Built around a 25 mm piston bore with 25 mm of travel, AVENTICS 1322502000 is a double-acting roundline cylinder from the ICM series. For the 25 x 25 mm size, air enters through G 1/8 connections, maximum working pressure is 10 bar and the operating range is -20 °C to +70 °C.
- Bore x stroke: 25 x 25 mm
- ICM series, double-acting
- Pneumatic connection: G 1/8
- Piston rod thread: male
- Elastic cushioning type
- Maximum operating pressure 10 bar; -20 °C to +70 °C
For pricing, please contact our experts.
