AVENTICS 0822343902 | Pneumatic Guided Cylinder | 63 mm Bore, 80 mm Stroke, TRB Series

Name: AVENTICS 0822343902 | Pneumatic Guided Cylinder | 63 mm Bore, 80 mm Stroke, TRB Series
Brand: Aventics
SKU: 0822343902
Availability: OutOfStock

Part Number : 0822343902

Where a 80 mm stroke is needed at 63 mm bore, the AVENTICS 0822343902 double-acting TRB guided cylinder fits the requirement. G 3/8 connections, pneumatic cushioning and ISO 15552 conformity complete the 0822343902 specification.

Bore 63 mm, stroke 80 mm, double-acting
Pneumatic cushioning
Piston rod thread: male
Conforms to ISO 15552
Manufacturer series: TRB
Maximum operating pressure: 10 bar
Works between -20 °C and +80 °C

Availability: in stock

Detailed Description
Specifications
Downloads

The Aventics Series TRB Tie Rod Cylinder is an industry-leading solution designed to meet the demanding requirements of heavy-duty applications. Engineered to ISO 15552 standards, this cylinder ensures exceptional reliability and performance across various sectors, including steel, automotive, and mining. With a piston diameter of 63 mm and a versatile stroke length of up to 2500 mm, this cylinder adapts seamlessly to your specific needs. Its robust double-acting design and adjustable pneumatic cushioning offer superior control and efficiency, minimising wear and extending the lifespan of both the cylinder and your machinery. Notably, this cylinder is built to withstand a wide temperature range and offers optional ATEX certification, making it suitable for use in diverse environmental conditions. The innovative features and thoughtful design make the Series TRB an invaluable asset for any industrial operation aiming for high-performance standards.

Double-acting design provides enhanced control and efficiency
Built to ISO 15552 standards for compatibility and reliability
Pneumatic adjustable cushioning reduces wear and improves lifespan
Wide ambient and medium temperature range supports diverse applications
Lightweight construction facilitates easy installation and operation
Exceeds industry norms with optional ATEX certification for hazardous environments
Customisable stroke lengths up to 2500 mm for flexible applications
Stainless steel and polyurethane materials ensure durability and resistance

Brand	AVENTICS
Manufacturer Series	TRB
Model Number p	0822343902
Bore	63mm
Action	Double
Stroke	80mm
Pneumatic Connection	G 3/8
Port Connection	G 3/8
Piston Rod Thread Gender	Male
Cushioning Type	Pneumatic Cushioning
Maximum Operating Pressure	10 bar
ISO Standard	15552
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+80°C

AVENTICS 0822343902 | Pneumatic Guided Cylinder | 63 mm Bore, 80 mm Stroke, TRB Series

DOWNLOAD CATALOG

0822343902 Datasheet - 0822343902 A700000012561951

0822343902 Datasheet - 0822343902 A700000012562291
