AVENTICS 0822010899 | KHZ Piston Rod Cylinder | 100 mm Bore, 100 mm Stroke, Double Acting

Name: AVENTICS 0822010899 | KHZ Piston Rod Cylinder | 100 mm Bore, 100 mm Stroke, Double Acting
Brand: Aventics
SKU: 0822010899
Availability: OutOfStock

Part Number : 0822010899

Bore 100 mm, stroke 100 mm: the AVENTICS 0822010899 is a KHZ piston rod cylinder that acts in both directions. Air is supplied through G 1/4 ports, with a 10 bar pressure ceiling for the 0822010899.

0822010899: 100 mm bore, 100 mm stroke, double acting
Temperature range of model 0822010899: -25 to +80 °C
Elastic cushioning and female piston rod thread on model 0822010899

Availability: in stock

Detailed Description
Specifications
Downloads

The Aventics Short Stroke Cylinder from aventics is meticulously designed for maximum efficiency in confined spaces. The series KHZ integrates seamlessly into machinery, offering both safety and ease of use. Its compact dimensions do not compromise on performance, making it a reliable choice for diverse industrial applications. With a robust build tailored to withstand industry standards, this model excels in environments that demand reliability and durability. The double-acting functional principle ensures consistent performance, making this cylinder an essential component in various pneumatic systems.

Stainless steel piston rod promotes corrosion resistance and longevity
Nitrile rubber piston material supports effective sealing and longevity
Scraper material made of polyurethane optimises debris management
Features elastic cushioning for smooth operation and reduced wear
Operating temperature ranges meet demanding industrial requirements
Environmentally resistant materials suitable for harsh conditions

Brand	AVENTICS
Manufacturer Series	KHZ
Model Number p	0822010899
Action	Double
Bore	100mm
Stroke	100mm
Pneumatic Connection	G 1/4
Port Connection	G 1/4
Piston Rod Thread Gender	Female
Cushioning Type	Elastic
Maximum Operating Pressure	10 bar
Maximum Operating Temperature	+80°C
Minimum Operating Temperature	-25°C

AVENTICS 0822010899 | KHZ Piston Rod Cylinder | 100 mm Bore, 100 mm Stroke, Double Acting

DOWNLOAD CATALOG

0822010899 Datasheet - 0822010899 A700000012571293
