AVENTICS 0821300911 Rotary Knob 3/2 Pneumatic Manual Control Valve NL4-BAV Series, G 1/2, 1/2in, III B

Name: AVENTICS 0821300911 Rotary Knob 3/2 Pneumatic Manual Control Valve NL4-BAV Series, G 1/2, 1/2in, III B
Brand: Aventics
SKU: 0821300911
Availability: OutOfStock

Part Number : 0821300911

Availability: Sold out

Detailed Description
Specifications
Downloads

NL Series 3/2 Shut-Off Valve Manual

Shuts off supply pressure and gently relieves downstream pressure
Ball valve with metal to metal sealing
Padlock lockable
Working pressure 0 → 60 bar
Temperature range -10 → +60 °C
ATEX certified II 2G2D X

NL Series FRL

The NL range of air preparation units may be used as single elements or in combination units using joining accessories

Brand	AVENTICS
Control Mechanism	Rotary Knob
Connection Port Thread	G 1/2
Function	3/2
Thread Size	1/2in
Thread Standard	G
Manufacturer Series	NL4-BAV
Maximum Operating Pressure	16 bar
Body Material	Die Cast Zinc
Maximum Flow Rate	11000L/min
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+60°C
Number of Ports	3/2
Model Number p	III B
