ASCO 18900002.120/60, Solenoid Valve , 3 port(s) , NC, 120 V, 3/4in

Name: ASCO 18900002.120/60, Solenoid Valve , 3 port(s) , NC, 120 V, 3/4in
Brand: Asco
SKU: 18900002.120/60
Availability: OutOfStock

Part Number : 18900002.120/60

Availability: Sold out

Detailed Description
Specifications

The Asco solenoid valve is an innovative solution designed for advanced valve piloting applications. It features a compact design, ensuring that it integrates seamlessly into various installations without compromising on performance. This direct-operated valve operates with both normally closed and normally open configurations, making it a versatile choice for different operational needs. Engineered to meet stringent EU directives, it provides reliable performance under varying conditions. The valve supports a wide temperature range, making it suitable for diverse environments while maintaining exceptional durability, thanks to its robust materials. Whether for air or inert gas applications, this solenoid valve stands at the forefront of efficiency and safety, offering easy installation on both single and joinable subbases.

Designed for valve piloting applications with a CNOMO pad-mount version
Low weight enables effortless installation in tight spaces
AC/DC interchangeability ensures versatility without disassembly
M12 connection option includes visual indication for enhanced user interaction
Compatibility with joinable subbases allows for flexible configurations
Integrated manual operator ensures reliability during maintenance
Manufactured from high-quality materials to ensure compatibility with fluids
Robust electrical enclosure protection rated at IP65 enhances durability

Brand	Asco
Supply Voltage	120 V
Number of Ports	3
Connection Size	3/4in
Connection	3/4 in G
Operation	Direct
Default Valve Position	NC
Suitable Applications	Air, Inert Gas
Type	Solenoid
Orifice Diameter	1.2mm
Series	189
Body Material	Polyamide
Maximum Working Pressure	10 bar
Operating Temperature Range	-10 → +60 °C
Servo Assist	No
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-10°C
Thread Standard or Connection Type	G
Flow Factor Kv	1.2L/min
