SMC IP8100-031 | Electro-Pneumatic Positioner | Rotary Type | Series 8100 | Port Connection G1/2
The IP8000 E/P positioner has better visibility of the pressure indication and is smaller than the IP6000. Additional features include a 1/2 split range that may be easily adjusted by span, interchangeable installation, superior shock and vibration performance, and enhanced enclosure protection IP65. The IP200 cylinder positioner allows air cylinders to be positioned precisely and steadily. The small size makes maintenance and installation simple. The feed-back spring can be adjusted using a span adjuster and a zero adjuster.
- Specifications
- Features
- Downloads
| Material | Aluminium |
| Output Current | 4-20mADC |
| Port Type | G1/2 |
| PRESSURE | 1.0 MPa |
| Series | 8100 |
| Stroke | 60 to 100 |
| Thread type | Rc1/4 |
| Type | Electro-pneumatic rotary type |
| Vibration | Resistance: No resonances 5 to 200Hz |
| Weight | 2.9 Kg |
- Output Current (4-20mADC): Enables remote position detection for rotary type applications.
- Vibration Resistance: No resonances from 5 to 200Hz, ensuring stable performance in vibrating environments.
- Dust Resistance: Conforms to JIS F8007 IP65, providing protection against dust and water ingress.
- Pressure Gauge O.D.: 43mm, offering clear and accurate pressure readings.
- Accessories Included: Comes with an output restriction with a pilot valve, fork lever joint, compensation spring, and an external scale plate for versatile installation and use.
